| 品牌 | WILO/威乐 | 型号 | MVI1604/6-1/16/E/3-380-50-2 | 材质 | 不锈钢 |
| 性能 | 增压 | 用途 | 增压泵 | 泵轴位置 | 边立式 |
| 叶轮结构 | 封闭式叶轮 | 叶轮吸入方式 | 单吸式 | 流量 | 20（m3/h） |
| 扬程 | 50（m） | 吸入口径 | 50（mm） | 排出口径 | 50（mm） |
| 规格 | MVI1604/6-1/16/E/3-380-5 |
产品型号：
| MVI1602/6-1/16/E/3-380-50-2 |
| MVI1603/6-1/16/E/3-380-50-2 |
| MVI1604/6-1/16/E/3-380-50-2 |
| MVI1605/6-1/16/E/3-380-50-2 |
| MVI1606/6-1/16/E/3-380-50-2 |
| MVI1607/6-1/16/E/3-380-50-2 |
| MVI1608/6-1/16/E/3-380-50-2 |
| MVI1609/6-1/16/E/3-380-50-2 |
| MVI1610/6-1/16/E/3-380-50-2 |
| MVI1602/6-1/25/E/3-380-50-2 |
| MVI1603/6-1/25/E/3-380-50-2 |
| MVI1604/6-1/25/E/3-380-50-2 |
| MVI1605/6-1/25/E/3-380-50-2 |
| MVI1606/6-1/25/E/3-380-50-2 |
| MVI1607/6-1/25/E/3-380-50-2 |
| MVI1608/6-1/25/E/3-380-50-2 |
| MVI1609/6-1/25/E/3-380-50-2 |
| MVI1610/6-1/25/E/3-380-50-2 |
Feature/特征:
Stainless steel materials/不锈钢材质
High pressure by multi-stage impeller/多级叶轮，高扬程
Easy maintenance by bidirectional mechanical seal/双向机械密封，易维护
CQC certification/获得中国节能认证证书
Application/应用:
Water supply and pressure boosting/供水和增压
Hot water circulation and heating system/热水循环和采暖系统
Air-conditioning systems/空调系统
Industrial circulation systems/工业循环系统
Washing and sprinkling systems/清洗及喷洒灌溉系统
For various machinery/各种机器配套
